Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
RPS
Green
Red
Gray
The switch is receiving power from the redundant power
supply.
RPS has failed.
RPS is not installed or RPS monitoring is disabled.
DUPLEX Green
Orange
The port is operating at full duplex.
The port is operating at half duplex.
Note - AT-9816GB, AT-9816GF and AT-9816GB-DC share the same device image.
Note - To turn RPS monitoring on or off on the switch, from the switch command line interface
enter the command SET SYSTEM RPSMONITOR={ON|OFF}. To see whether RPS monitoring is
on, use the command SHOW SYSTEM. To turn on RPS monitoring using SNMP, set the
fanAndPsRpsMonitoringStatus variable to on.
Note - The current firmware version does not allow AT-View Plus Device Manager to support the
RPS LED on the AT-9816GB-DC model.
Agent Menu
From the Agent menu, you can view and edit the system information for the switch, or log into the
CLI using Telnet.
System Info
Displays basic system information, including system name,location,contact and description.
Firmware Info
Displays a list of software releases installed on the switch.
File List
Displays a list of the files in the switch's file system.
Config File Name
Displays the file name of the start-up configuration file.
Chassis Temperature Info
Displays the actual temperature of the switch and the temperature status.
Telnet
Starts a Telnet connection to the switch.
