Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Expansion Module Notes
• When the Port Speed and Mode parameter of an AT-A14 expansion module port is set to
'auto sense' and the port is connected to a 100Mbps full duplex port on another device, its
corresponding Duplex LED on the device image turns orange instead of green.
• The current firmware version does not allow the Port Speed and Mode parameter of the AT-
A14 expansion module port to be set to any value other than 'auto-sense'.
• A GBIC image is always visible on the GBIC slot of the AT-A15 expansion module image
even if there is no GBIC physically present in the slot.
• The Port Speed and Mode parameter of an AT-A15 expansion module port must match the
duplex mode of the port to which it is connected in order to establish connection.
• The current firmware version does not allow AT-View Plus Device Manager to distinguish
the AT-A16, AT-A17, and AT-A19 expansion modules from each other. With the connector
type (VF-45, SC, MT-RJ) being the only difference among them, all three expansion
modules have been made to share the same GIF image.
• Attempting to configure the Port Speed and Mode parameter of an AT-A16/AT-A17/AT-
A19 expansion module port to '10Mbps half-duplex' or '10Mbps full-duplex' will
automatically set it to '100Mbps half-duplex' or '100Mbps full-duplex' respectively.
• The current firmware version does not allow the Port Speed and Mode parameter of the AT-
A17 expansion module ports to be set to 'auto sense'.
• When the Port Speed and Mode parameter of an AT-A18 expansion module port is set to
'auto sense' and the port is connected to a full duplex port on another device, its
corresponding Duplex LED on the device image turns orange instead of green.
AT-8200XL Series
PN 613-50665 Rev A Page 44 of 257
