At-8748xl, Main window – Allied Telesis AT-VIEW PLUS 3.0 DEVICE MANAGEMENT User Manual
Page 147
Allied Telesyn
AT-VIEW PLUS
DEVICE MANAGEMENT
AT-8748XL
This section describes AT-View Plus Device Manager menus and operations specific to the AT-
8748XL and AT-8748XL-DC Advanced Layer 2 Switches.
Topics:
•
•
•
•
•
Main Window
AT-8748XL
Device Manager LEDs for AT-8748XL
LED
State
Description
PWR
Green
Red
The switch is receiving power from the main power supply.
Main power supply is either off or has failed.
PN 613-50665 Rev A
Page 147 of 257
