Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Call List Menu
Displays ISDN call information such as ISDN number and call direction for active calls.
Displays information about currently active ISDN calls.
Displays port statistics such as the number of frames received and transmitted on the port,
bytes received and transmitted on the port, and port status.
Displays error statistics.
Displays the port's spanning tree parameters.
Disable
From the Call List menu, you can view ISDN call information. The Call List submenus are greyed
out if the device is not configured for ISDN.
Detail Info
Active call
Port Menu
From the Port menu, you can view and edit MIB information about the port.
Utilization
Displays the port's utilization information.
Interface Info
Error Statistics
Spanning Tree Info
Enable
Enables the port.
Disables the port.
Rapier 16F/MT and 16F/SC
PN 613-50665 Rev A Page 163 of 257
