Status
The status of the control entry.
Owner
The owner (creator) of the control entry.
7.2.3.2 Select Button
: changes the control entry displayed in the Statistics window. To change an
entry displayed, select the entry in the table, then click the Select button. Data
collected for the selected entry is displayed on other tabs thereafter.
Note - When you edit the current entry, or when you add an entry with the same
index number after removing the current entry, make sure to select the entry
again. Otherwise, the changes will not take effect on the other tabs.
7.2.3.3 Add Button
: adds a new entry to the RMON Statistics control table. When you click this
button, the Add Control Table Entry dialog box appears. Enter the Index, the
Data Source and the Owner, then click OK to create an entry.
Add Control Table Entry dialog box
7.2.3.4 Edit Button
: changes the selected entry. To edit the entry, select an entry on the table
then click the Edit button. The Modify Control Table Entry dialog box appears.
Change the required parameters, then click OK. You can also open the dialog
box by double-clicking the desired entry.
