Note

- Only the values of the collected RMON variables are saved. Values Device

Manager calculates from these collected values are not saved.

7.3.7.5 Start Snapshot

Clicking this button opens the Start Snapshot window. Use this window to
create an image of the device, as well as tables or charts representing device

information, in HTML format. Use the 'Browse' button to select the directory
or folder where you want to save the image.

Note

- You can generate an image of the main panel, table data, or charts. The

type of image or device information that you can generate depends on which
menu you opened the Start Snapshot window from. For more information on
the file types created in the Start Snapshot window, see section

5.2.6

.

Start snapshot
