Request Buckets

The number of values which you asked the RMON agent to store.

Granted Buckets

The number of values the RMON agent allows you to store.

Sampling Interval

The time interval at which the RMON agent collects data.

Status

The status of the control entry.

Owner

The owner (creator) of the control entry.

7.3.3.2 Select Button

: changes the control entry displayed in the History window. To change the

control entry displayed, select an entry in the table, then click the Select button.
Data collected by the selected entry is displayed on other tabs thereafter.

Note

- To display changes to the current entry, or to display a new entry with the

same index number as a previously removed entry, be sure to select the current
entry. Otherwise, the changes will not take effect on the other tabs.

7.3.3.3 Add Button

: adds a new entry to the RMON History control table. When you click this

button, the Add Control Table Entry dialog box appears. Enter the following
parameters, then click OK to create an entry.

Index

The index number used to identify this entry.

Data Source

The index of the interface on which the RMON agent collects data.

Request Buckets

The number of values which you want the RMON agent to store.

Sampling Interval

The interval at which the RMON agent retrieves data.

Owner

The creator (owner) of this entry.

AlliedView™-EMS 3.10 Device Manager User’s Guide

Page 106 of 133
