AlliedView™-EMS 3.10 Device Manager User’s Guide Page 113 of 133
Absolute Value
Displays the sum of values which Device Manager got from the RMON
agents, as shown in the following example.
Data sampled by RMON Data displayed by Device Manager
Sample 1 100 100
Sample 2 50 150
Sample 3 250 400
Per Sample
Displays data which Device Manager got from the RMON agent as it is.
Data sampled by RMON Data displayed by Device Manager
Sample 1 100 100
Sample 2 50 50
Sample 3 250 250
Per Second
Displays "Sampled data / Sampling Interval configured on the RMON
agent". The sampling interval here is the RMON agent's sampling interval,
not the interval configured in Device Manager. In the following example,
the RMON agent's sampling interval is 10 seconds.
Note - Calculated values are rounded. For example, the Number of Error
packets is usually very small so that the calculated value is likely to be
zero.
Data sampled by RMON Data displayed by Device Manager
Sample 1 100 10 (100 / 10)
Sample 2 50 5 (50 / 10)
Sample 3 250 25 (250 / 10)
7.3.7.3 Regist Menu
Add this window to the user-defined User Menu.
7.3.7.4 Save Polling Data
This button opens the Polling Data Save dialog box, used to save collected data
to a file. Specify the name and format of the file in which the data is to be saved.
Select a file format from the options below. To start saving the data, click OK.
When you start saving data, the button's label changes to "Saving polled data".
To close the file and stop saving the data, click the "Saving polled data" button.
CSV Format
Saves the data in comma-separated values (CSV) format.
TAB Format
Saves the data in tab-separated values (TSV) format.
