Index of the RMON Event entry which is triggered when the sampled
value reaches the rising threshold. If you select "falling alarm" for the
Start Alarm Type, this defaults to zero. Because an Event Index of 0 is
invalid and there is no event related to Index 0, no event will occur even if
the rising alarm is triggered.
TRAP Community
Trap Community name.
Event Description
Text string describing the event. By default, "Rising Event for Alarm#idx"
is used where "idx" represents the Alarm index number.
Falling Alarm Event Rule
Configuration for the falling alarm. If you select "rising alarm" for the
Startup Alarm Type, only "Falling Threshold" and "Falling Event Index"
can be configured. If there is no Event entry corresponding to the Event
Index, no event will occur.
Falling Threshold
The floor threshold. If the monitored variable falls below this threshold, a
falling alarm event occurs. The default is 2000.
Event Type
The type of action to be taken when the event occurs. Select one of
"none" (no action taken), "SNMP trap" (send an SNMP trap), "log"
(record to the log) and "log & SNMP trap" (record to the log and send an
SNMP trap).
Falling Event Index
The index of the RMON Event entry which is triggered when the sampled
value falls below the falling threshold. If you select "rising alarm" for the
Start Alarm Type, this defaults to zero. Because an Event Index of 0 is
invalid and there is no event related to Index 0, no event will occur even if
falling alarm is triggered.
TRAP Community
Trap Community name.
Event Description
Text string describing the event. By default, "Falling Event for
Alarm#idx" is used where "idx" represents the Alarm index number.
7.4.4 Edit Button
: edits the selected Alarm entry. Click this button to open a dialog box,
specify options, then click OK. You can also open this dialog box by double-
clicking the entry.
