6.4.7 Get MIB Value Button
: Updates the MIB Value fields of the selected variables. To select a variable,
click the MIB Variable field of the target variable.
6.4.8 Set MIB Value Button
: Changes the values of the checked variables, using the SNMP Set operation.
The values in the MIB Value fields are sent to the SNMP agent on the device.
Note - SNMPv3: Depending on the WRITE VIEW access settings of the User
Account Name used, there is a possibility that Device Manager may not be able
to set some MIB values. When this happens, a "No access error." value will be
displayed on the affected MIB Value cells.
Note - SNMPv3: If the User Account Name does not have READ VIEW but has
WRITE VIEW access for a MIB variable, you may still set the value of that
variable. However, the new value will not be displayed on the affected MIB
Variable cells.
Note - SNMPv3: Device Manager still allows the user to set values for the
following parameters even if the user has No Write access to these:
• System Name
• System Contact
• System Location
The write attempt will eventually fail and the value, "No access error" will be
displayed on the value column for the said parameters. Additionally, the new
values set will be displayed on the Panel Window, but once the user refreshes
the display, the values on the Panel Window will be reset to the original values
set on the device.
6.4.9 Threshold Button
: Set a threshold on the selected variable. The threshold is used to monitor
the variable's value. If the threshold is exceeded, the action configured on the
Options menu is executed. To select a variable, click the MIB Variable field of
the target variable. When you click the Threshold button, the Edit Threshold
Item dialog box appears.
AlliedView™-EMS 3.10 Device Manager User’s Guide Page 79 of 133
