m an LC-compatible 68030 processor-direct slot (PDS). The
DOS-compatibility card is already installed in this slot; you cannot add
another card to it.
Note: The process you use to install a TV tuner card is different from the one
described in this appendix. See the documentation that came with that card
for instructions.
Installing an expansion card or SIMM involves three steps:
m opening the computer
m inserting the card or SIMM into a particular slot
m closing the computer
WARNING To avoid damaging your computer and expansion card, do
not attempt to install any expansion card without first checking the
documentation for that card. If the documentation specifies that an
Apple-certified technician must install the card (usually because
the installation requires special training or tools), consult the service
and support information that came with your computer for instructions
on how to contact an Apple-authorized service provider or Apple for
assistance. If you attempt to install the card yourself, any damage you
may cause to the computer or card will not be covered by the limited
warranty on your computer. If the card is not an Apple-labeled product,
check with an Apple-authorized dealer or service provider to see if you
can install it yourself.
Video-in slot
Communication slot
Vertical plate
LC-compatible PDS slot
(with DOS-compatibility card installed)
145 Installing an Expansion Card or Memory for the PC Environment
