C
HAPTER
8____________________________________________
SELF
-
TESTING AND PROBLEM HANDLING
V
AISALA
_________________________________________________________________________ 69
C n Listing transducer coefficients
C n
where n = number of the pressure transducer (1, 2 or 3)
The C n command is used to list all internal coefficients of a
transducer. These coefficients are for factory use only and they cannot
be changed by the user. For transducer P1, the listing looks as follows:
>c 1
Y03
:
6408
Yp
:
18400
0
Xp
:
929
5283
Zp
:
0
0
0
R
:
25
A0
:
32501
120
118
-3
120
A1
:
-12947
-96
175
11
0
A2
:
-1538
-3
58
0
A3
:
-147
-1
0
A4
:
-18
0
A5
:
0
Offset :
0
Gain
:
0
Zero
:
0
Yt
:
10000
0
Xt
:
0
0
Zt
:
4197
498
0
Rt
:
4
A0
:
5104
32446
5288
0
0
0
Offset :
0
Gain
:
0
Low
:
500
High
:
1100
>
For transducers P2 and P3, the listings can be obtained in a similar
way.
PTEST Testing pulse output mode
PTEST
The PTEST command is used to test the operation of pulse output
mode.
The PTEST command outputs the pressure reading or some other user
defined pressure reading in the form of a pulse output. The pulses
come out soon after the PTEST command is given to the barometer.
