2. Installing the Console

Installing the AC Power Adapter

1. Find the power jack located on the bottom of the console case.

2. Insert the power adapter plug into the console power jack then plug the

other end of the adapter into an appropriate power outlet.

3. Check to make sure the console runs through a brief self-test procedure

successfully. The console will display all the LCD segments and then
beep twice.

4. After power-up the console automatically enters Setup mode. Setup

mode guides you through steps required to configure the station. See
“Setup Mode” on page 11 for more information.

Installing Batteries

1. Remove the battery cover located on the back of the console by pressing

down on the two latches at the top of the cover.

2. Insert three C batteries into the battery channel, negative (or flat) terminal

first.

Power Plug

Wrap Cord Around Pins

Batter
