Configuration
46 UDM-0102 and UDM-RX02 Operation/Reference Guide
1. Click on the Schedule option (on the left of the page) to access a listing of all scheduled events that
have already been created (FIG. 64).
2. To create a combination event, click each schedule’s Preset link - the individual schedule numbers
appear in the Preset bar at the bottom of the screen.
3. Set the frequency details; select one of the following from the Frequency drop-down menu
(FIG. 58):
4. Enter the Hour and Minute for this event in the text fields to the right of the Frequency drop-down
menu (see FIG. 65).
5. Assign the Preset schedule a unique name by replacing the default text (FIG. 65).
FIG. 64 Main Schedule page (indicating previously created scheduled events)
FIG. 65 Preset Schedule - Frequency and Time options
Hour Event happens at a specified time and then every 60 minutes.
Day Event happens at a specified time and then every 24 hours.
Weekday Event happens at a specified time and then every 24 hours (Mon. through Fri.).
Sunday Event happens every Sunday at the specified time.
Monday Event happens every Monday at the specified time.
Tuesday Event happens every Tuesday at the specified time.
Wednesday Event happens every Wednesday at the specified time.
Thursday Event happens every Thursday at the specified time.
Friday Event happens every Friday at the specified time.
Preset links
Preset bar
Select frequency for this Preset
Enter Hour for this Preset
Enter Minute for this Preset
Click to add
this Preset to
the Hub
Default preset name
Specify an interval
(minutes between
individual events in
this Preset)
These Frequency settings override any previously created frequency / times used in
the Preset schedule.
