Configuration
42 UDM-0102 and UDM-RX02 Operation/Reference Guide
6. Enter the Hour and Minute for this event in the text fields to the right of the Frequency drop-down
menu (see FIG. 54 on page 42).
7. Click Add to save this scheduled event to the Hub. The new event information is displayed as shown
in FIG. 55:
8. Click on the checkbox shown in FIG. 55 to enable this scheduled event for use. Each scheduled
event must be enabled before it can be used.
FIG. 54 Input Schedule - Frequency and Time options
Hour Event happens at a specified time and then every 60 minutes.
Day Event happens at a specified time and then every 24 hours.
Weekday Event happens at a specified time and then every 24 hours (Mon. through Fri.).
Sunday Event happens every Sunday at the specified time.
Monday Event happens every Monday at the specified time.
Tuesday Event happens every Tuesday at the specified time.
Wednesday Event happens every Wednesday at the specified time.
Thursday Event happens every Thursday at the specified time.
Friday Event happens every Friday at the specified time.
FIG. 55 Displayed Scheduled Event
Select frequency for this event
Enter Hour for this event
Enter Minute for this event
Click to add
this event to
the Hub
Click here to enable this
scheduled event for use
Click here to test this
scheduled event
You can test the schedule at any time by pressing the Execute link.
