Using the Cross-Os File Exchange Software 4-23
Hitachi USP V Cross-OS File Exchange User’s Guide
OPEN-8 5818 5818 5818 9959 (min 9996*n-7,
65534)
OPEN-9 5818 5818 5818 10009 (min 10016*n-7,
65534)
OPEN-E not
supported 5818 5818 19752 (min 19759*n-7,
65534)
OPEN-L not
supported 5818 5818 49429 (min 49439*n-7,
65534)
OPEN-V not
supported not supported not supported 65534 (min(Vc*n*128/
96-7,65534)
(see Note 4)
Note 2: XX = 1 or 2; YY,x = number; ZZ<2x
Note 3: For Solaris, the data cylinder must be less than or equal to 32767.
When using a LUSE volume, the geometry parameter is different, so the
number of cylinders should be calculated as follows:
Cylinder (specified to FAL formatting) <= (A*B*C) / (15*96) – 5
A: Head (Geometry parameter)
B: Block/Track (Geometry parameter)
C: cylinder (Geometry parameter)
Note 4: Vc = OPEN-V cylinder value (MAX.:49160 cylinders using FAL)
The FMT utility can be used on standard-size OPEN-x volumes and on Virtual
LVI/LUN (VIR) volumes.
Note: The VIR OPEN-x devices can also be called custom volume size (CVS)
devices (e.g., OPEN-3-CVS). When formatting a VIR OPEN-x LU, use the
number of cylinders defined for VIR minus seven (e.g., use 993 cylinders for a
VIR device defined with 1000 cylinders). The cylinder size is: one cylinder =
15 tracks, one track = 96 sub-blocks, one sub-block = 512 bytes. Table 3-9
shows the relation between block length and write available capacity per track.
The actual data capacity per cylinder = (write available capacity per track) ×
(15 tracks).
Table 4-2 Relation between Block Length and Write Available Capacity
per Track
Block Length by
Allocater = (A)
(Bytes)
Write Available
Data per Track
(Bytes)
Block Length by
Allocater = (A)
(Bytes)
Write Available
Data Per Track
(Bytes)
Block Length by
Allocater = (A)
(Bytes)
Write Available
Data Per Track
(Bytes)
23477 - 32760 (A) × 1 1589 - 1684 (A) × 22 565 - 596 (A) × 44
15477 - 23476 (A) × 2 1493 - 1588 (A) × 23 533 - 564 (A) × 45
11477 - 15476 (A) × 3 1397 - 1492 (A) × 24 501 - 532 (A) × 46
9077 - 11476 (A) × 4 1333 - 1396 (A) × 25 469 - 500 (A) Ч 47
