Using the Cross-Os File Exchange Software

4-15

Hitachi USP V Cross-OS File Exchange User’s Guide

–

{ = the dataset can be processed by FCU.
8 = the dataset cannot be processed by FCU.
? = the dataset can be processed by FCU only if the VSE record option is
used to specify the RF, RL, and BL.

–

Dataset = dataset name

–

DO = dataset organization type: SAM, DAM, PAM, VSAM, ? (other than
above)

–

RF = record format: F (fixed-length), V (variable-length), U (undefined),
S (spanned), ? (other than above)

–

BL = block length

–

RL = record length

–

DS = dataset size (in number of tracks)

Note: This example shows an FX volume (3380-KA, VSN = AAAAAA ) which contains only two datasets.

Note: When this panel is opened using the Mainframe file selection button (

), only SAM datasets are displayed.

Figure 4-10

MF-File Information Panel
