Description Item
Displays volume capacity. Open-system volumes are displayed in gigabyte (GB), mainframe
volume are displayed in cylinder (Cyl). For an expanded (LUSE) volume, the capacity of each
LDEV is available. Capacity
Displays the RAID level. RAID Level
Displays the data protection level. Protection
• SATA-W/V: Write & Verify method on SATA drives.
•
SATA-E: Enhancing method on SATA drives.
•
Standard: SAS drives, SSD, external volumes, or virtual volumes (V-VOLs).
Displays the hard disk type of internal volume as follows: Internal Volume
Information
•
Blank indicates SAS drive.
• An asterisk (*) indicates SATA drive.
•
The dollar sign ($) indicates SSD.
•
A hyphen (-) indicates external volume.
Displays the parity group. Parity Group ID
Indicates if the volume is encrypted or not. Encryption
•
Enable: The volume is encrypted.
• Disable: The volume is not encrypted.
•
A hyphen (-) appears when the volume is not an internal volume.
Displays the number of LU paths. Number of Paths
The attribute set for the volume as follows: Attribute
• Pool (X): The volume is set as a pool volume (pool-VOL), where X indicates pool ID.
•
V-VOL: The volume is set as a virtual volume (V-VOL) for Snapshot.
• V-VOL: The volume is set as a virtual volume (V-VOL) for Thin Provisioning.
•
Reserved LDEV: The volume is set as a reserved volume of Auto LUN.
•
JNL Volume: The volume is set as a journal volume.
• System Disk: The volume is set as a system disk.
Information on the external volume appears in the format of Vendor/ Product name/ Serial
number/ Hard disk type. For an internal volume, "-/-/-/-" appears. For a migration volume,
"-/-/-/ " appears. The hard disk type appears as follows: External Volume
Information
•
Blank indicates SAS drives.
• An asterisk (*) indicates BD or SATA drive.
•
The dollar sign ($) indicates SSD.
•
A hyphen (-) indicates internal volume.
Displays the number of LU paths that are set for the external volume. Number of External
Paths
Displays the Cache Mode set for the external volume when it was mapped. For an internal
volume or a migration volume, a hyphen (-) appears. Cache Mode
Displays the name and ID of the resource group where the LDEV is assigned. Resource Group
Name (ID)
174 Remote Web Console GUI reference (secondary windows)
