volume appears. Items displayed in the dialog box are the same as the items displayed in the
LDEV list.
•
LDEV ID column displays the LDKC number, the CU number, and the LDEV number. These
numbers are separated by colons (:). The following symbols might appear at the end of the
LDEV number:
◦ # (for example, 00:00:01#) indicates that the LDEV is an external volume.
◦ V (for example, 00:00:01V) indicates that the LDEV is a Snapshot virtual volume.
◦ X (for example, 00:00:01X) indicates that the LDEV is a Thin Provisioning virtual volume.
◦ M (for example, 00:00:01M) indicates that the LDEV is a migration volume.
The icons in the LDEV ID column have the following meaning:
Table 43 Icons in the LDEV ID column
Description Icons
Normal LDEV
Expanded (LUSE) volume
Reserved volume of Auto LUN
Variable-sized volume (CV)
Secured LDEV
Remote command device
Command device
Command device to which the command device security is applied
•
Use Export to save the displayed information as a comma-separated values (CSV) file.
•
Use Close to close the Report Display dialog box.
