Resize a print, Use the embedded web server, Use a driver – HP Designjet Z6100 Printer series User Manual

Page 95: Use the front panel

Use the Embedded Web Server

To set the margins through the Embedded Web Server, go to the Submit Job page on the Main tab.

In the Job Settings tree, select Advanced settings > Paper > Layout/Margins. Then use the

Select margins drop-down menu to set the margins. Select from: Default, Small, Normal and

Extended.

NOTE:

Be aware that when you submit more than one job at a time by clicking the Add files

button in the Embedded Web Server, all of the jobs that you submit will adopt the settings of the

final job that you submit. However, none of the jobs in the print queue are affected.

Use a driver

Specify the margins in the following ways:

●

In the Windows HP-GL/2 Normal margins and Standard layout are selected by default. To

change the margins and layout options, click the Paper/Quality tab and click the Layout button.

●

In the Windows PostScript driver, Normal margins and Standard layout are selected by default.

To change the margins, click the Paper/Quality tab, select More from the Document size drop-

down menu, and then select the desired page size and the margins at the same time. Click the

Layout button to change the layout options.

●

In the Mac OS driver, select Page Setup from the File menu, select your printer in the in the Format

for popup menu, and then select Paper size. You select the page size and the margins at the same

time.

NOTE:

In the Windows PostScript driver, you have the option of selecting a paper size with no

margins. The No margins option should only be selected in conjunction with the Oversized

and Clip contents by margins layout settings.

NOTE:

In Mac OS driver, the available margins options depend on the paper size that you

selected in the Page Setup dialog box.

You have the option of selecting a paper size with no margins. To select the No margins option,

click the Printing dialog, select the Finishing panel, and then click the Layout tab. The No

margins option should only be selected in conjunction with the Oversized and Clip contents

by margins layout settings.

Use the front panel

On the front panel, select the

icon, and then select Printing preferences > Margins > Select

margins.

Resize a print

You can send an image to the printer at a certain size but tell the printer to resize it (normally larger). This

can be useful in the follow situations:

●

If your software does not support large formats

●

If your file is too large for the printer's memory. In this case, you can reduce the page size in your

software and then scale it up again by using the front-panel option

Resize a print 83
