Configuring the 5258ACL Tape Drive for the
NonStop Himalaya S-Series Server

5258ACL Installation and User’s Guide 522345-001

4 -5

Configuring the Modular Tape Drive Online Using

SCF (PMF/IOMF)

For a blank PMF FRU Configuration, refer to the Himalaya S-Series Planning and
Configuration Guide.

Complete the SCSI Port information block on the form if attaching a tape drive to a
PMF CRU:

Enter the Subsystem Control Facility (SCF) name of the tape drive in the SCF Name
field.

Enter the product number of the copper SCSI cable to be used with this tape drive in
the SCSI Cable field. Use one of the copper SCSI cables listed in

Table 2-1

on

page

2-8

.

For instructions on completing the rest of the PMF CRU Configuration Form, refer to
the Himalaya S-Series Planning and Configuration Guide.

Configuring the Modular Tape Drive Online Using
SCF (PMF/IOMF)

Use the Subsystem Control Facility (SCF) to configure tape drives for the NonStop

TM

Himalaya S-Series processors. SCF allows adding, changing of the attributes, and
deleting a tape drive. You can run SCF from any terminal attached to the system after
logging on.

Using SCF, you can do the following:

Obtain configuration information about a tape drive

Restore access to a tape drive

Stop access to a tape drive if there is no activity

List tape drive status

Switch the primary processor for a tape drive

This section provides examples of configuring cartridge tape drives using SCF. The
examples show how to define and add a tape drive to the system configuration. For a
complete description of how to configure and manage tape drives using SCF, see the
SCF Reference Manual for the Storage Subsystem.

For information about how to use SCF to configure, control, and inquire about all
supported subsystems for the NonStop

TM

Himalaya S-Series server, see the SCF

Reference Manual for the Storage Subsystem.

Example 1: Defining and Adding a Tape Drive (PMF/IOMF)

Use the SCF ADD TAPE command to define and add a 5258ACL tape drive to the
system configuration. Before issuing the ADD TAPE command, ensure that the tape
drive is installed properly. The following example adds a 5258ACL drive FRU,
“$TAPE0,” to the system configuration:

-> ADD TAPE $TAPE0, SENDTO STORAGE, LOCATION (1,1,55), &
-> DEVICEID 5, PRIMARYCPU 0, BACKUPCPU 1,
