Operating the 5258ACL Tape Drive
5258ACL Installation and User’s Guide — 522345-001
3- 18
Removing the Magazine
Removing the Magazine
When the magazine door is closed, it is locked in place to prevent tampering or
accidental removal. To remove the magazine, enter the Menu mode by pressing Enter at
the Default screen. At the Main menu, select Unlock Door and press Enter. The
magazine door swings open.
Emergency Magazine Removal
If a fault occurs that prevents removal of the magazine, turn the power off for 30
seconds. Power up while continuously pressing the
# scroll button. Continue to hold the
button until all of the indicators on the control panel are lit and then go out. Release the
button and the door swings open.
Inserting a Magazine Into the 5258ACL
If the magazine door on the front of the module is closed and locked, to open it:
1. Enter the Menu mode by pressing Enter at the Default screen.
2. At the Main menu, select Unlock Door and press Enter. The magazine door swings
open.
3. Slide the magazine through the door opening, with the cartridges protruding from
the left.
4. When the magazine is fully inserted, push the door closed until it locks.
Inserting Cartridges Into the Magazine
A full magazine is shown in Figure 3-22 . Insert cartridges so that the label end with the
write protect switch is outward and toward the bottom of the magazine. After the desired
cartridges are inserted into the magazine, position the module so the cartridges protrude
to the left, and the magazine handle is toward the operator (
Figure 3-22 ). Insert the
magazine into the 5258ACL drive with this orientation.
