Contents
5258ACL Installation and User’s Guide — 522345-001
iii
4. Configuring the 5258ACL Tape Drive for the
NonStop Himalaya S-Series Server
Displaying Firmware Revision 3-16
Displaying Error Logs 3-16
Inserting and Removing Cartridges 3-17
Removing the Magazine 3-18
Emergency Magazine Removal 3-18
Inserting a Magazine Into the 5258ACL 3-18
Inserting Cartridges Into the Magazine 3-18
Tape Requirements 3-19
Cartridge Handling and Storage 3-20
Write Protection 3-21
Loading and Unloading Tapes 3-21
4. Configuring the 5258ACL Tape Drive for the NonStop Himalaya S-
Series Server
Supported Connections 4-1
Configuring the Modular Tape Drive for the NonStop Himalaya S-Series Servers
(SNDA) 4-2
Configuring the Modular Tape Drive Online Using SCF (SNDA) 4-2
Example 2: Changing the Values of Tape Drive Attributes (SNDA) 4-2
Example 3: Deleting a Tape Drive From the System (SNDA) 4-3
Configuring the Modular Tape Drive for the NonStop Himalaya S-Series Servers
(PMF/IOMF) 4-3
Completing the PMF CRU Configuration Form (PMF/IOMF) 4-4
Configuring the Modular Tape Drive Online Using SCF (PMF/IOMF) 4-5
Example 1: Defining and Adding a Tape Drive (PMF/IOMF) 4-5
Example 2: Changing the Values of Tape Drive Attributes (PMF/IOMF) 4-6
Example 3: Deleting a Tape Drive From the System (PMF/IOMF) 4-7
5. Maintenance for the 5258ACL
Cleaning Cartridge 5-1
Required Location for the Cleaning Cartridge 5-1
Installing 5-2
When to Run 5-2
Running From the Front Panel 5-2
Removing the Cleaning Cartridge 5-4
