Operating the 5258ACL Tape Drive
5258ACL Installation and User’s Guide — 522345-001
3- 13
Map Information Screen
•
Product Type
•
Tape Format
•
Compression
•
SCSI Bus ID
•
Drive Revision
•
Controller Revision
•
Cartridge Present
•
Hardware Error
•
Cleaning Needed
•
Write Protected
•
Operate Handle
•
Drive Serial No.
Map Information Screen
When Map Info is selected, a screen similar to Figure 3-14 appears. The location of the
element being reported appears on line 1 in place of “Location.”
Figure 3-14. Map Info Submenu
Lines 1, 2, 3, and 4 of this screen are scrollable in unison. For each scroll position, line 1
displays one of the following locations:
•
DLT1
•
Slot 1 through Slot 10
If the host software license permits fewer slots than the magazine contains and if
reserved slots have been designated in accordance with that license, or to use the
Autoclean mode, a lesser number of slots are displayed. The procedure for designating
reserved slots is described in Section 2, “Installing and Configuring the 5258ACL
Drive.”
Depending on the presence or absence of a cartridge in the element being reported, line
2 displays either “Empty” or “Occupied.”
Depending on the report for each location, line 3 displays either “Label Valid” or “Label
Not Present.”
L o c a t i o n
% % % %
E l e m e n t S t a t u s
L a b e l S ta t u s
X X X X X X X X
# # # #
