Operating the 5258ACL Tape Drive

5258ACL Installation and User’s Guide 522345-001

3 -5

Display Messages

The media can be locked by software running on the host, using the SCSI Allow/Prevent
Medium Removal command. The 5258ACL provides no control panel override for this
command. Exiting the host, you can restore media access by cycling 5258ACL power.

Display Messages

The control panel display can show messages of up to four lines of 20 characters each.
Many of these messages and their functions are described next. Those displays that are
described in other sections are cross-referenced here.

Power-On-Self-Test Screen

When power is first applied to the module, a series of power-on self-test (POST)
diagnostics are performed. During POST execution, the model number of the module,
the current date and time, the firmware revision, and the status or result of the test in
progress are displayed on the control panel, as shown in

Figure 3-3

.

Figure 3-3. POST Screen

Initialization Screens

After the POST is completed, the library robotics system begins initialization and series
of screens similar to

Figure 3-4

appear.

Figure 3-4. Initialization Screen

Default Screen

After the POST diagnostics have concluded successfully, and initialization is complete,
the default screen shown in

Figure 3-5

appears.

Figure 3-5. Default Screen

525X ACL
Firmware Level 0X.xx
Checking Hardware

525X ACL
Firmware Level 0X.xx
Initializing Loader
26-Feb-19xx 15:35:59

SDLT1 No Tape
Loader Idle
