Operating the 5258ACL Tape Drive

5258ACL Installation and User’s Guide 522345-001

3- 23

Loading and Unloading Tapes

Press Enter to select DLT1. Notice that, in

Figure 3-27

, two changes occur in the

display:

The * reappears at the beginning of line 2, indicating that a selection has been made.

The

"

now moves to line 4, indicating that a destination has been selected.

Figure 3-28. Load/Unload To Entry Screen

Press Enter to select Slot 2 as the destination. Note that there is an

!

at the end of line 4.

Additional choices are available because 1) a drive has been selected as the source, so
the destination must be a slot, and 2) all of the slots except Slot 1 are empty, so a list of
remaining empty slots appears below Slot 2. To select Slot 4, scroll down until Slot 4
appears on line 4. Press Enter to select Slot 4. In response, the confirmation screen in

Figure 3-28

appears.

Figure 3-29. Confirmation Screen

As the confirmation screen indicates, to execute the load or unload, press Enter. If the
confirmation screen does not show the intended source and destination, press Escape to
return to the To entry screen.

When Enter is pressed, the screen shown in

Figure 3-29

appears. If the source were a

slot, the message “Load” would appear in place of the message “Unload” on line 4.

Figure 3-30. Load/Unload ‘In Progress’ Screen

From:
*SDLT1
To:
"

"

"

"*Slot

#

#

#

#

From: SDLT1 To: Slot4

ENTER To Execute
ESCAPE To Cancel

From: SDLT1 To: Slot4

Unload In Progress
