Operating the 5258ACL Tape Drive
5258ACL Installation and User’s Guide — 522345-001
3 -6
Display Messages
The first line of the Default Screen the status of the DLT drive within the 5258ACL.
Possible status conditions are:
•
No Tape
•
Idle
•
Rewinding
•
Seeking
•
Reading
•
Writing
•
Erasing
•
Cleaning
•
Unloaded
•
Loading
•
Unloading
•
Calibrating
The screen's second line displays possible status conditions of the library robotics:
•
Loader Idle
•
Fetch
•
Stow
•
Diag Active
•
Diag Complete
•
Taking Inventory
•
Elevator Home
•
Checking Drive(s)
•
Orphaned Cartridge
•
Trapped Cartridge
•
Scanning Labels.
The third line in Figure 3-5 represents a map of the tape magazine. A 10-slot magazine
is shown. The number 1 shows the location of Slot 1 (the front slot) in the map. The
number 10 shows the location of Slot 10 (the rear slot) in the map. A rectangle on this
line indicates that a cartridge is present in the corresponding slot of the magazine. An
underline means that no cartridge is present.
