Operating the 5258ACL Tape Drive
5258ACL Installation and User’s Guide — 522345-001
3- 10
Exiting the Main Menu
Exiting the Main Menu
To leave the Menu mode and return to the Default screen, press Escape repeatedly. Each
time Escape is pressed, the display moves up a menu level. When the Main menu is’
visible, pressing Escape once returns you to the Default screen.
Navigating the Main Menu
To select a submenu, move the
"
to the desired line by using the
#
and
!
scroll
buttons. Press Enter to confirm the selection and display the submenu. The
!
at the end
of the fourth line of the Main menu means that there are one or more additional options
can be reached by scrolling, using the
!
button. The options are:
•
Load/Unload
•
Unlock Door
•
Show Status Menu
•
Maintenance Menu
•
Configure Menu
•
Show History Menu
•
Security Menu.
The submenus that correspond to each of the Main menu selections are described next.
Load/Unload
The Load/Unload submenu is described later in this section under “Loading and
Unloading Tapes.”
Unlock Door
If you scroll to Unlock Door and press Enter, the magazine door swings open.
Note. When an
$
is seen on line 1 or an
!
on line 4 of the display, you can scroll up and
down to reveal more options.
Note. If the message “Magazine Locked” appears, the host software has locked the tape
magazine. Exiting the backup or HSM software usually releases the lock. In the event of host
failure, the software will cycle the power to the 5258ACL to release the lock.
