HP Virtual Connect 4Gb Fibre Channel Module for c-Class BladeSystem User Manual
Page 78

Storage management 78
Number of uplinks
FC connectivity for device bays
2 uplinks in any combination
(1-2, 1-3, 1-4, 2-3, 2-4, or 3-4)
Least # uplink - 1, 3, 5, 7, 10, 12, 14,
16
Next # uplink - 2, 4, 6, 8, 9, 11, 13, 15
3 uplinks in any combination
(1-2-3, 1-2-4, 1-3-4, 2-3-4)
Least # uplink - 1, 4, 7, 10, 13, 16
Next # uplink - 2, 5, 8, 11, 14
Next # uplink - 3, 6, 9, 12, 15
4 uplinks
(All uplinks 1, 2, 3 and 4)
Uplink #1 - 1, 5, 11, 15
Uplink #2 - 2, 6, 12, 16
Uplink #3 - 3, 7, 9, 13
Uplink #4 - 4, 8, 10, 14
VC 8Gb FC module
Number of uplinks
FC connectivity for device bays
1 uplink
1-16
2 uplinks in any combination
Least # uplink - 1, 3, 5, 7, 10, 12, 14,
16
Next # uplink - 2, 4, 6, 8, 9, 11, 13, 15
3 uplinks in any combination
Least # uplink - 1, 4, 7, 10, 13, 16
Next # uplink - 2, 5, 8, 11, 14
Next # uplink - 3, 6, 9, 12, 15
4 uplinks in any combination
Least # uplink - 1, 5, 11, 15
Next # uplink - 2, 6, 12, 16
Next # uplink - 3, 7, 9, 13
Next # uplink - 4, 8, 10, 14
5 uplinks in any combination
Least # uplink - 1, 6, 11, 16
Next # uplink - 2, 7, 12
Next # uplink - 3, 8, 13
Next # uplink - 4, 9, 14
Next # uplink - 5, 10, 15
6 uplinks in any combination
Least # uplink - 1, 7, 12
Next # uplink - 2, 8, 13
Next # uplink - 3, 14, 15
Next # uplink - 4, 9, 16
Next # uplink - 5, 10
Next # uplink - 6, 11
