Server management 113
Column name
Description
Port Speed Setting
The requested operational speed for the server port. Valid values include
"Auto", "Preferred", and "Custom".
If the speed type is "Auto", the maximum port speed is determined by the
maximum configured speed for the network.
If the speed type is "Preferred", the speed of the network is the same as the
preferred speed of the network to which the connection is associated. If no
preferred speed is configured for a network, it defaults to "Auto".
If the speed type is "Custom", the user can configure any speed from
100Mb-MAX Configured speed for the network in 100Mb increments.
Allocated Bandwidth
Allocated bandwidth of the port. See Bandwidth assignment (on page
PXE
Enables or disables PXE on the network connection. Valid values are
"enabled", "disabled", and "UseBios". If this value is not specified, the
default is "UseBios".
Only one connection can have PXE enabled per profile.
MAC
The MAC address assigned to the port, or "Server Factory Default" if not
using VC-assigned MAC addresses
Mapping
Server hardware mapping assignment. See Port assignment (on page
Delete When
the
X in the column is bold, this line item is eligible for deletion.
FC SAN Connections (Physical
ports)
Port
Relative order of the Fibre Channel port on the server receiving the profile
Connected to
Bay number of the VC-FC module to which the port is connected
FC SAN name
Name of the SAN fabric to which the port is connected, or Unassigned
Status
Status of the Fibre Channel module
Port speed
Speed of the VC-FC module port connected to the port
WWPN
The World Wide Port Name assigned to the port or Server Factory Default
if not using VC-assigned MAC addresses
Delete When
the
X in the column is bold, this line item is eligible for deletion.
Assign Profile to Server Bay
Power
Icon indicates if the server blade is powered on or off (when a server is
selected).
Server Bay Assignment
Displays the enclosure name, bay number, and type of server blade
S/N
Serial number of the server blade in the device bay
Model
Model name of the server blade in the device bay
Status
Status of the server blade in the device bay
UID
Icon indicates if the server blade UID is on or off.
The following table describes the available actions in the Edit a Server Profile screen. Clicking another
link in the pull-down menu or left navigation window causes current edits that have not been applied to be
lost.
Task Action
Edit a profile name
Type a name in the Profile Name field.
