HP Virtual Connect 4Gb Fibre Channel Module for c-Class BladeSystem User Manual
Page 44

Domain management 44
The VC-Enet SNMP settings apply to all VC-Enet modules in the Virtual Connect domain.
The following table describes the fields within the SNMP Settings (SNMP Enet Settings) screen.
Field name
Description
Enable SNMP
Select to enable SNMP
System Contact
Specify contact name for this system when SNMP is enabled
Read Community
Controls SNMP read access when SNMP is enabled. The default value for read
community string is "public". The read community string must always be set when
SNMP is enabled.
SNMP Alert Destinations
SNMP trap destination table. Maximum number of trap destinations allowed is
five.
After entering an IP address and community string, click Add.
To remove an IP address, highlight the address, and then click Remove.
IP Address
SNMP trap destination IP address
Community String
The Community String acts like a password for a given trap destination. The trap
receiving application can use the community string to filter the incoming traps.
Default: public
To apply changes made on this screen, click Apply.
