Hardware information screens 141
The following table describes the rows within the Uplink Port information table in the Bay Summary
screen.
Column Description
Port
The uplink port number
WWN
Either the World Wide Name assigned to the port or the Server Factory
Default, if not assigning WWNs
SAN Fabric
Name of the SAN Fabric connected to the uplink port
Port Speed
Speed setting of the uplink port
Connector Status
Status of the uplink port
Connected To
MAC address of the device that this port is connected to on the other end.
The device must support LLDP to display this information.
The following table describes the rows within the Server Port Information table in the Bay Summary
Screen. Click Less < to display only the Port, Server Blade, SAN Fabric, Connected To, and Profile
columns. Click More > to display all columns.
Column Description
Port Port
number
Server Blade
Server blade bay location
SAN Fabric
Name of the SAN Fabric connected to this port
Connected To
WWN address of the device that this port is connected to on the other end
Profile
Server Profiles with connections to this port
HBA Port
HBA port number
HBA Port Speed
Speed setting of the HBA port
HBA Port Status
Status of the HBA port
HBA WWPN
Either the World Wide Port Name assigned to the port or the Server Factory
Default, if not assigning WWNs
Administrative module removal
The Remove from Domain feature enables users to remove an interconnect module from the Virtual
Connect domain without having to delete the entire domain, or having the bay permanently configured
for a specific interconnect module type.
To temporarily remove the module from the domain, do not click Remove from Domain. Simply re-install it
into the enclosure.
To permanently remove the module from the Virtual Connect domain be sure the following conditions are
met:
NOTE:
The attachment of stacking link cables to a module does not prevent a Remove from
Domain action.
•
VC-Enet conditions:
o
The user must have Domain privileges.
o
The module must be physically removed from the bay.
