Hardware information screens 135
Port Statistic
Description
EtherStatsOversizePkts
The total number of packets received that were longer than 1518 octets
(excluding framing bits, but including FCS octets) and were otherwise
well-formed.
EtherStatsJabbers
The total number of packets received that were longer than 1518 octets
(excluding framing bits, but including FCS octets), and had either a bad
FCS with an integral number of octets (FCS Error) or a bad FCS with a
non-integral number of octets (Alignment Error). This definition of jabber
is different than the definition in IEEE-802.3 section 8.2.1.5 (10BASE5)
and section 10.3.1.4 (10BASE2). These documents define jabber as
the condition where any packet exceeds 20 ms. The allowed range to
detect jabber is between 20 ms and 150 ms.
EtherStatsOctets
The total number of octets of data (including those in bad packets)
received on the FCS octets). This object can be used as a reasonable
estimate of Ethernet utilization. If greater precision is required, the
StatsPkts and StatsOctets objects should be sampled before and after a
common interval. The differences in the sampled values are Pkts and
Octets, respectively, and the number of seconds in the interval is
Interval. These values are used to calculate the Utilization as follows:
Utilization = [(Pkts * (9.6 + 6.4) + (Octets * .8)) / (Interval * 10,000)].
The result of this equation is the value Utilization which is the percent
utilization of the Ethernet segment on a scale of 0 to 100 percent.
EtherStatsPkts
The total number of packets (including bad packets, broadcast packets,
and multicast packets) received.
EtherStatsCollisions
The best estimate of the total number of collisions on this Ethernet
segment. The value returned depends on the location of the RMON
probe. Section 8.2.1.3 (10BASE-5) and section 10.3.1.3 (10BASE-2)
of IEEE standard 802.3 states that a station must detect a collision, in
the receive mode, if three or more stations are transmitting
simultaneously. A repeater port must detect a collision when two or
more stations are transmitting simultaneously. Therefore, a probe placed
on a repeater port could record more collisions than a probe connected
to a station on the same segment would. Probe location plays a much
smaller role when considering 10BASE-T.
14.2.1.4 (10BASE-T) of IEEE standard 802.3 defines a collision as the
simultaneous presence of signals on the DO and RD circuits (transmitting
and receiving at the same time). A 10BASE-T station can only detect
collisions when it is transmitting. Therefore, probes placed on a station
and a repeater should report the same number of collisions.
Additionally, an RMON probe inside a repeater should ideally report
collisions between the repeater and one or more other hosts (transmit
collisions as defined by IEEE 802.3k) plus receiver collisions observed
on any coax segments to which the repeater is connected.
EtherStatsCRCAlignErrors
The total number of packets received that had a length (excluding
framing bits, but including FCS octets) of between 64 and 1518 octets,
inclusive, but had either a bad FCS with an integral number of octets
(FCS Error) or a bad FCS with a non-integral number of octets
(Alignment Error).
TXNoErrors
All packets transmitted without errors, less oversized packets.
RXNoErrors
All packets received without errors, less oversized and undersized
packets.
