Introduction 12
Depending on the product being connected to the HP APM, the HP APM connects to the system components
using various cables. All cables required for connecting the HP APM to the system must be purchased
separately.
Item Component
Connects To
1
HP Apollo a6000 Chassis
The RDM1 connector on the HP APM
2
HP Apollo 6000 Power Shelf The Power Distribution Module ports on
the HP APM
3
HP APM
—
4
Power Distribution Unit
The Power Distribution Module ports on
the HP APM
5
HP ProLiant SL Series Chassis Server port on the RDM
6
HP ProLiant SL Series Chassis Server port on the RDM
7
HP Moonshot 1500 Chassis Server port on the RDM
8
HP Intelligent Modular PDU
Managed Extension Bar
The Power Distribution Module ports on
the HP APM
9
Production network
Ethernet port on the HP APM
