Chapter 6 Installing an Additional Processor
46
Refer to Chapter 2, "Opening and Closing the HP NetServer," to gain
access to the system board.
NOTE It is not necessary to remove the system board from the
NetServer to install the second processor (CPU 2).
6. Lay the NetServer on its side (components showing).
7. Unlatch the air duct and move it out of the way. See Figure 6-2.
Latch Opening
Air Duct
Latch
Figure 6-2. Moving the Air Duct
8. Ensure the processor speed of the second processor (CPU 2) is the same as
the existing processor before installing the second processor.
NOTE If you are upgrading the second processor to a faster processor
speed than the primary processor, the primary processor must
also be changed. Both processors must have the same product
number, which includes the same clock speed, cache size, and
FSB speed.
The supported processors only perform at the rated speed
indicated on the processor in the HP NetServer.
