Chapter 5

Installing Additional Boards

39

NOTE

Refer to "System Board Layout" in the Appendix A,
"Specifications" for connections not shown in Figure 5-1.

PCI Slot 5

PCI Slot 1

PCI Slot 6

PCI Slot 2

PCI Slot 7

64-bit

32-bit

32-bit

32-bit

64-bit

System Board (Top View)

Wake-
On-
LAN

Figure 5-1. Accessory Slots

NOTE

Refer to the Readme file, Tested Products List, or
Configuration Advisor on your HP NetServer Navigator
CD-ROM for specific slot recommendations for a particular
PCI board type.
