Chapter 3 Installing Mass Storage Devices
16
Installed Mass Storage Devices
Table 3-1 lists the number and types of mass storage devices that may be installed
into the HP NetServer E 800.
Table 3-1. SCSI Mass Storage Device Types
Interface
Types
Max Number
of Devices Installed Devices and Addresses
Flexible disk
drive
1 Factory installed flexible disk drive in (top)
shelf 1
IDE-1 2* Factory installed CD-ROM drive in shelf 2
(Primary IDE connector)
Ultra SCSI
Adapter
1**
(optional)
Optional SCSI Tape Backup Drive in shelf 3
(address = ID 4)
Ultra-2 SCSI
Channel A
up to 4 ***
•
Factory installed SCSI hard drive in
shelf 4 (address = ID 0)
•
Up to three additional SCSI hard disk
drives in shelves 5, 6, and 7 of the
removal hard disk drive cage
(addresses = ID 1, 2, 3)
•
Optional duplexing of at least two SCSI
drives in shelves 4, 5, 6, and 7
•
Embedded SCSI controller
(address = ID 7)
Ultra-2 SCSI
Channel B
up to 15 ***
•
Optional duplexing of up to two SCSI
drives in shelves 4, 5, 6, and 7.
•
Optional control of up to 15 external
SCSI devices
* The primary IDE (IDE-1) cable is connected to the factory-installed CD-
ROM drive. A secondary IDE connector (IDE-2) is available, but is not
supported by Hewlett-Packard.
** A 50-to-68-pin SCSI adapter is provided with the HP tape drive.
*** Both SCSI channels (A and B) can each support up to 15 devices;
however, there are only enough internal storage shelves for four hard drives
and one optional tape backup device. Channel B is typically used to control
external SCSI devices. If you decide to duplex internal drives using Channel
B, you are restricted to the internal drives only.
