Chapter 1 Controls, Ports and Indicators
4
NOTE For more information on the HP Tape Drive and its error
codes, refer to the documentation provided with the tape drive
or refer to Hewlett-Packard’s web site, at:
http://www.hp.com
Refer to Chapter 3, "Installing Mass Storage Devices," for
installation information.
Rear View
The ports and connectors at the rear are listed below and shown in Figure 1-3.
•
The power connector accepts a standard power cable to connect the
HP NetServer E 800 with the site power supply.
•
The mouse port accepts a standard mouse with a PS/2 connector.
•
The keyboard port accepts a standard keyboard with a PS/2 connector.
•
Two USB ports are provided for printers, scanners, and external modems.
•
The LAN port is included as an embedded controller based on Intel’s
82559 10/100 BaseT Fast Ethernet controller. It has a RJ-45 LAN
connector and two LEDs to indicate LAN speed and valid connection.
Refer to Table 1-3 for the LAN LED indicators.
•
The Serial Port A is a standard serial port.
•
The Parallel Port is a standard parallel port which supports Extended
Capabilities Port (ECP)/Enhanced Parallel Port (EPP).
•
The Serial Port B is a standard serial port.
•
The Monitor Port interface specifications are listed in Table A-4, "HP
NetServer Hardware Specifications" and Table A-5, "Video Display
Modes" of Appendix A, "Specifications."
•
The optional external SCSI port provides access to external SCSI devices.
The optional HP NetServer E 800 Internal/External SCSI Cable Kit
(PN: P1774A) is required to install an external SCSI port.
