Chapter 3 Installing Mass Storage Devices
19
Slots for Tabs
Captive
Screws (3)
First, insert screws through
round holes in back
(one each side).
Tabs(2)
Figure 3-2. Adding a Hard Disk Drive
CAUTION All mounting screws used to thread into the hard disk drive
must be #6-32 and not exceed ¼-inch in length. Longer
screws may cause internal damage to the mass storage device.
Damage caused by incorrect mounting screws is not covered
by the HP warranty.
10. Align the drive's screw holes with the holes in the hard disk drive cage and
install the screws to secure the drive to the hard disk drive cage.
a. Attach one of the screws through the round screw hole at the rear of the
cage.
b. Attach another screw through the round hole at the front of the cage on
the same side.
