ADDITIONAL STATUS
The additional status contains 4 bytes of Status for the SRD991 .
These bytes may be reset via a reset status under the test menu . This action will also clear the More Status flag within the
Secondary Status and the SSTAT-Err flag within the Primary Status, if the Secondary Status is empty .
Byte 1 contains system errors. The individual bits of the status byte are defined below . When the specified condition exists,
the status bit will be set to One otherwise, the status bit will be Zero . Byte 3 contains the same information but historically -
that is the condition existed but has been cleared .
7
6
5
4
3
2
1
0
Output
Supply
Autostart
Control
LowLow
HiHi
Low
High
Press
Press
Fail
Diff
Alarm
Alarm
Alarm
Alarm
Alarm
Alarm
• Bit 6 - Feedback failed; the feedback lever or coupling is out of range
• Bit 5 - Trimming of Input Loop Current failed; uncertain range in use
• Bit 4 - Cycle Count Limit reached; enough cycles completed to warrant planned maintenance
• Bit 3 - Travel Sum Limit reached; enough cycles accumulated to warrant planned maintenance
• Bit 2 - Configuration not valid
• Bit 1 - Device temperature too low
• Bit 0 - Device temperature too high
Byte 2 contains process errors. When the specified condition exists, the status bit will be set to One otherwise, the status bit
will be Zero . Byte 4 is again a historical version of byte 2 .
7
6
5
4
3
2
1
0
Output
Supply
Autostart
Control
LowLow
HiHi
Low
High
Press
Press
Fail
Diff
Alarm
Alarm
Alarm
Alarm
Alarm
Alarm
• Bit 7 - Output Pressure Alarm; pressure is out of range
• Bit 6 - Air Supply Pressure Alarm; pressure is out of range
• Bit 5 - Auto start failed; positioner operation will only be correct if fully set up manually .
• Bit 4 - Control difference out of limit; operation sluggish or not possible, may be untuned
• Bit 3 - Travel Position low low alarm
• Bit 2 - Travel Position high high alarm
• Bit 1 - Travel Position low alarm
• Bit 0 - Travel Position high alarm
High Alarm
This is a 4-byte real, expressed as percentage of stroke . When the valve position exceeds this parameter, the Hi Alarm status
bit in the secondary device status will be set . Default for this parameter is 110% .
7
6
5
4
3
2
1
0
Control Diff
LoLo Alarm
HiHi Alarm
Low Alarm
High Alarm
NOT USED
More Status
Failsafe
Timeout
Additional Status
