Characteristics of Curve
Equal Percentage (1:50) Invers Equal Percentage (50:1) Equal Percentage (1:25)
X Y X Y X Y
0 .00% 0 .00% 0 .00% 0 .00% 0 .00% 0 .00%
0 .20% 2 .16% 2 .00% 0 .00% 2 .00% 4 .27%
13 .20% 3 .35% 2 .40% 4 .66% 12 .00% 5 .89%
23 .20% 4 .96% 2 .80% 8 .60% 21 .20% 7 .91%
27 .60% 5 .89% 3 .20% 12 .01% 29 .60% 10 .37%
32 .00% 6 .99% 3 .60% 15 .02% 37 .20% 13 .25%
36 .00% 8 .18% 4 .00% 17 .72% 44 .40% 16 .70%
40 .00% 9 .56% 4 .40% 20 .15% 50 .80% 20 .52%
43 .60% 11 .01% 4 .80% 22 .38% 56 .80% 24 .90%
47 .20% 12 .67% 5 .60% 26 .32% 62 .80% 30 .20%
50 .40% 14 .37% 6 .00% 28 .08% 68 .40% 36 .16%
53 .60% 16 .28% 6 .80% 31 .28% 73 .60% 42 .75%
56 .80% 18 .45% 8 .00% 35 .44% 78 .40% 49 .90%
59 .60% 20 .59% 9 .20% 39 .01% 80 .80% 53 .91%
62 .40% 22 .97% 10 .80% 43 .11% 83 .20% 58 .24%
65 .20% 25 .63% 12 .40% 46 .64% 87 .60% 67 .10%
68 .00% 28 .60% 14 .00% 49 .74% 90 .00% 72 .49%
70 .40% 31 .41% 16 .00% 53 .15% 92 .00% 77 .31%
72 .80% 34 .50% 18 .00% 56 .17% 94 .00% 82 .45%
75 .20% 37 .90% 20 .40% 59 .37% 96 .00% 87 .93%
77 .60% 41 .63% 22 .80% 62 .21% 98 .00% 93 .78%
80 .00% 45 .73% 25 .20% 64 .77% 100 .00% 100 .00%
82 .40% 50 .23% 28 .00% 67 .46%
84 .40% 54 .32% 31 .20% 70 .23%
86 .40% 58 .74% 34 .40% 72 .72%
88 .40% 63 .52% 38 .00% 75 .27%
90 .40% 68 .69% 41 .60% 77 .58%
92 .40% 74 .28% 45 .60% 79 .93%
94 .40% 80 .32% 50 .00% 82 .28%
96 .40% 86 .86% 54 .40% 84 .44%
98 .40% 93 .93% 64 .00% 88 .59%
100 .00% 100 .00% 74 .80% 92 .58%
86 .80% 96 .38%
100 .00%
Configuration / Parameter
