SHIMPO CAG-2000 1 Channel User Manual
Page 9
7
EXT
I/
RS2
32C
SW
.E
TC
ANA
LO
G
(14) RS232C connector
A serial communication connector for connecting a personal
computer or printer.
(15) Switch input connector
A connector for input of a measure or mastering command with
an external button. It is also used for RS422 communication
and Digimatic output (options).
(16) Analog input/output connector
A connector for external analog signal input and amplifier signal
output.
(14)
(15)
(16)
