34
11. I/O Description
11.1 Serial output (RS232C)
(1) Description
This instrument can output the measured values to a printer and communicate with a
personal computer through RS232C.
Command Symbol
Hold measured value E
Clear measured value hold
Clear master request
R
Request measured value D
Minimum-mastering N
Maximum-mastering X
Change to Program 1 P01
Change to Program 4 P04
(2) Preparation
The RS232C connector at the rear of the instrument is provided for the personal
computer or printer. Connect the D-sub 9-pin (male) plug of an optional
communication cable to the RS232C connector. Three types of optional
communication cables are available for specific applications. For details, refer to
“13. Options”.
(3) Setting serial port
Baud rate: 9600
Bits/character: 8
Stop bit: 1
Start bit: 1
Parity bit: None
