8
5. Specifications
Item Specification Remarks
Input 1 air channel
Air supply pressure 0.196 MPa Source pressure:
0.3 MPa or more
Measurement item 1
CAG2000 0.0200, 0.0500, 0.100, 0.200
CAG2000E 0.0250, 0.0500, 0.100, 0.200
Measuring range (mm)
CAG2000H 0.0100, 0.0200, 0.0500, 0.1000
CAG2000 0.0002, 0.0005, 0.001, 0.002
CAG2000E 0.00025, 0.0005, 0.001, 0.002
Resolution (mm)
CAG2000H 0.0001, 0.0002, 0.0005, 0.0010
Bargraph display 101 dots (red, green, orange, light/dark)
Bargraph display
method Bar (OK: Green, NG: Red), Dots (Max/Min)
Range display 2 digits (numbers), 2 places
Multifunctional display 8 digits (numbers/alphabet)
Measured value, set item, set value, and
error display
Shift range ±1000% (full scale) From Version 2.60
Actual dimension
display 000.0000 mm (7 digits + decimal point)
Judgment result ±NG and OK
Judgment result
display Bargraph display (color), judgment LEDs
Multifunctional display
Automatic mastering Minimum and maximum masters
Automatic mastering
range Zero position: ±50% (full scale)
Sensitivity: ±20% (full scale)
Number of setting
programs 10
Power supply voltage
and frequency 85 to 264 VAC, 50/60 Hz 100-VAC power cable
supplied as accessory
Power supply capacity 30 VA
Dimensions and mass 50 mm wide × 480 mm high × 200 mm deep,
4 kg
Operating temperature 0 to 45 °C
