8
TECHNICAL DATA
72
H250
www.krohne.com 04/2011 - 4000269302 MA H250-R02 en
Indicator M9 ESK3-PA Profibus
Terminal connection 2.5 mm 2
Bus cable R´ 15...150 Ohm/km
Bus cable L´ 0.4...1 mH/km
Bus cable C´ 80...200 nF/km
M9 ESK3PA Hardware
Hardware acc. to IEC 1158-2 and FISCO model
Supply voltage 9...32 VDC
Base current 12 mA
Starting current < base current
FDE (fault drop electronics) < 18 mA
Accuracy acc. to VDI/ VDE 3513 1.6
Measurement resolution < 0.1% full scale value
Temperature influence < 0.05% / K full scale value
Software firmware version 1.01/000418
Ident No. 3184980200
M9 ESK3PA Software
GSD Devices master file
Device profile Profiles B, V3.0
Function blocks
Flow rate (AI0) Volume or mass
Totalizer (TOT0) Volume totalizer
Default unit: [m
3 ]
Totalizer (TOT1) Mass totalizer
Default unit: [kg]
Address range 0...126, default 126
SAP`s Service Access Points
DD Device Description
