TECHNICAL DATA
8
77
OPTISENS MAC 100
www.krohne.com 04/2011 - MA OPTISENS MAC 100 R01 en
Other conditions Other conditions Other conditions Other conditions
Humidity (ambient) Max. 90% at 40°C / 104°F
Pressure For information about the process pressure of the used sensor(s) refer to the
relevant sensor documentation!
Protection category acc. to
IEC 529 / EN 60529:
IP66/67 (acc. to NEMA 4/4X)
Installation conditions
Installation Only wall mounting is possible, always assure a vertical mounting orientation!
Dimensions and weights For detailed information see chapter "Dimensions and weights".
Materials
Signal converter housing Die-cast aluminium (polyurethane coated)
Measuring sensor For housing materials, process connections, liners, grounding electrodes and
gaskets, see the technical documentation for the measuring sensor.
Electrical connections
General Electrical connection is carried out in conformity with the VDE 0100 directive
"Regulations for electrical power installations with line voltages up to 1000 V" or
equivalent national regulations.
Power supply Power supply Power supply Power supply
Voltage 100…230 VAC (-15% / +10%), 50/60 Hz; 240 VAC + 5% is included in the tolerance
range.
12...24 VAC/DC (in preparation)
Power consumption 4.2 W, 10 VA at 230 VAC
Fuse 0.8 AT/250V (high breaking capacity ), 5 x 20 mm / 0.2 x 0.8"
Line frequencies 50/60 Hz
Power rating 22 VA (maximum)
Inrush current I
N, eff
= 97 mA, t
15
= 1.5 ms, t
Peak
= 200 µs, I
Peak
= 22.6 A
Cable entries 1 channel: 4 x M20
2 channels (separate temperature sensor): 3 x M20, double PG two times 5 mm /
0.20" screwed connection for sensor cables
2 channels (integrated temperature sensor): 3 x M20, double PG two times 8 mm /
0.31" screwed connection for sensor cables
