OPERATION

OPTISENS MAC 100

www.krohne.com

04/2011 - MA OPTISENS MAC 100 R01 en

B5, logbooks

B6, information

Level

Designation / function

Settings / descriptions

B5.1

status log

Contains the latest changes of the device status,for further information refer

to refer to

Status log and calibration log on page 61.

B5.2

calibration log

Contains the results of the latest calibrations,for further information refer to

refer to

Status log and calibration log on page 61.

Level

Designation / function

Settings / descriptions

This menu groups several other menus which contain device specific information. The build-up of the display is the

same for all menus:

•

1st line: ID No. of the circuit board

•

2nd line: software version

•

3rd line: production date

B6.1

C number

Identifies the type of electronics, is also located on the converter nameplate.

B6.2

process input A

Gives information about the electronical part of process input A.

B6.3

process input B

Gives information about the electronical part of process input B.

B6.4

SW.REV.MS

Gives information about the main software of the electronics.

B6.5

SW.REV.UIS

Gives information about the user interface of the device.

B6.7

Electronic Revision ER

Reference identification number, electronic revision and production date of

the device; includes all hardware and software changes
