Installation – KROHNE MAC 100 EN User Manual
Page 18
3
INSTALLATION
18
OPTISENS MAC 100
www.krohne.com
04/2011 - MA OPTISENS MAC 100 R01 en
The mounting plate is fixed at the back side of the device in the delivery condition. The following
drawings illustrate the proper mounting:
• Note the drawing above and mark all drill holes with the help of a pen, e.g. a felt pen (1).
• Fasten the device securely to the wall with the help of plugs, screws and the mounting
plate (2).
CAUTION!
Installation, assembly, start-up and maintenance may only be performed by appropriately
trained personnel. The regional occupational health and safety directives must always be
observed.
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Wall mounting with plugs
.book Page 18 Friday, April 1, 2011 4:59 PM
