TECHNICAL DATA
8
75
OPTISENS MAC 100
www.krohne.com 04/2011 - MA OPTISENS MAC 100 R01 en
Technical data
8.1 Measuring principle
The measuring principle depends on the used sensor(s), for further information refer to the
sensor manual(s).
8.2 Technical data table
INFORMATION!
•
The following data is provided for general applications. If you require data that is more
relevant to your specific application, please contact us or your local representative.
• Additional information (certificates, special tools, software,...) and complete product
documentation can be downloaded free of charge from the website (Download Center).
INFORMATION!
The following data are relevant only for the non-Ex version. For technical data of the Ex-version
refer to the Ex-manual.
Measuring system
Measuring principle Depends on the used sensor(s), for further information refer to the sensor
manual(s).
Application range Continuous measurement of parameters in liquid analysis applications.
Measuring range Depends on the used sensor(s), for further information refer to the sensor
manual(s).
Design
Construction A typical measuring system consists of:
• MAC 100 multiparameter signal converter
• 1 (or up to 2) sensors of the OPTISENS series
• Sensor cable
• MAA mounting assemblies
Option The device is available as a one channel (one signal input) or a two channel version
(two signal inputs). You can connect one sensor to the one channel version and up to
two sensors to the two channel version.
Sensors For further information refer to the manual of the relevant sensor.
Also note the table with the sensor input combinations on page 15.
