C5, device
Level Designation / function Settings / descriptions
This menu groups all functions that have no effect on the measurement or any output directly.
C5.1 C5.1 C5.1 C5.1 device info Information about the device.
C5.1.1 tag Refer to A2 "tag".
C5.1.2 C number Refer to B6.1 "C number".
C5.1.3 device serial no. Serial number of the system
C5.1.4 electronic serial no. Serial number of the electronics assembly
C5.1.5 SW.REV.MS Refer to B6.4 "SW.REV.MS".
C5.1.6 Electronic Revision ER Refer to B6.6 "Electronic Revision ER".
C5.2 C5.2 C5.2 C5.2 display Groups several function for the fine adjustment of the display.
C5.2.1 language Refer to A1 "language".
C5.2.2 contrast This function allows to adjust the contrast of the display (e.g. at extreme
temperatures). Note that a change of the contrast takes place immediately,
not just when the menu mode is excited! You cannot reset a change when
leaving the programming mode without saving the changes!
Range: -9…0…+9
C5.2.3 default display This function allows to set the default page in the normal measuring mode;
after a short delay period the display always returns to this page
automatically. Options:
• none: no default measuring page, i.e. the display always stays on the
currently selected page.
• 1. meas. page: set this page as default.
• 2. meas. page: set this page as default.
• status page: show only status messages as default page.
• graphic page: show only trend display of the first measuring result as
default page.
C5.2.5 information Contains serial number, user interface software version number and
production date of the circuit board.
C5.3 C5.3 C5.3 C5.3 1. meas. page This menu groups all settings for the first measuring page. The menus are
equal for the first and second measuring page.
C5.3.1 function This function allows to specify the number of lines which display the
measured value(s). Options:
• two lines: display shows two lines of measuring results on this page.
• three lines: display shows two three of measuring results on this page.
• one line: display shows one line of measuring results on this page.
C5.3.2 measurement 1.line This function allows to define which measured value appears in the first line
of the display. The available options depend on the hardware setting and the
kind of the sensor used, refer to the sensor manual for further information.
C5.3.3 range Range for the measurement (0…100%) which has been set in the previous
function: 0...xx.xx _ _ _ (format and unit depend on the measurement, see
above).
C5.3.4 limitation Limitation before applying the time constant.
Range: -150…+150%
C5.3.5 time constant Range: 000.1…100 seconds
